Description
| Camera | |
| Image Sensor | 2 MP CMOS |
| Signal System | PAL/NTSC |
| Resolution | 1920 (H) × 1080 (V) |
| Frame Rate | TVI: 1080p @ 25fps/30fps AHD: 1080p @ 25fps/30fps CVI: 1080p @ 25fps/30fps CVBS: PAL/NTSC |
| Min. Illumination | 0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s |
| Lens | 2.8 mm Lens |
| Field of View | Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 123° |
| Lens Mount | M12 |
| Day & Night | ICR |
| WDR (Wide Dynamic Range) | Digital WDR |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Menu | |
| Image Mode | STD/HIGH-SAT |
| AGC | Yes |
| Day/Night Mode | Auto/Color/BW (Black and White) |
| White Balance | Auto |
| AE (Auto Exposure) Mode | DWDR, BLC, Global |
| Noise Reduction | 2D DNR |
| Language | English |
| Function | Brightness, Mirror, Smart IR, Sharpness |
| Interface | |
| Video Output | Switchable TVI / AHD / CVI / CVBS |
| General | |
| Operating Conditions | -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
| Power Supply | 12 VDC ± 25% |
| Consumption | Max. 3.3 W |
| Material | Plastic |
| IR Range | Up to 20 m |
| Communication | HIKVISION-C |
