Description
Video and Audio
IP Video Input
32-ch
Up to 12 MP resolution
Incoming Bandwidth
256 Mbps
Outgoing Bandwidth
256 Mbps
HDMI Output
4K (3840 × 2160) / 30Hz, 1920 × 1080p / 60Hz, 1600 × 1200 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
VGA Output
1920×1080p / 60Hz, 1280×1024 / 60Hz, 1280×720 / 60Hz, 1024×768 / 60Hz
Video Output Mode
HDMI / VGA independent output
Audio Input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 k Ω)
Decoding
Decoding Format
H.265+, H.265, H.264+, H.264
Decoding Capability
2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)
Synchronous playback
16-ch
Recording Resolution
12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p
Stream Type
Video, Video & Audio
Audio Compression
G.711ulaw / G.711alaw / G.722 / G.726 / AAC
Network
Network Protocol
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Remote Connection
128
Network Interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA
2 SATA interfaces
Capacity
Up to 10TB capacity for each HDD
USB Interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out
4/1
General
Power Supply
12 VDC, 3.33 A
Consumption
≤15 W (without HDD)
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10% to 90%
Dimension (W × D × H)
385 × 317× 52 mm (15.2″ × 12.5″ × 2.0″)
Weight
≤ 1 kg (without HDD, 2.2 lb.)
Certification
CE
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
Obtained Certification
CE, CB, UKCA, IC
