Description
Video / Audio input
IP video input
32-ch
Up to 12 MP resolution
Two-way audio
1-ch, RCA (2.0 Vp-p, 1 k Ω)
Network
Incoming bandwidth
256 Mbps
Outgoing bandwidth
256 Mbps
Remote connection
128
Video / Audio output
Recording resolution
12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
CVBS output (Optional)
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
HDMI output resolution
4K (3840 × 2160) / 60Hz, 4K (3840 × 2160) / 30Hz,1920 × 1080p / 60Hz,1600 × 1200 / 60Hz,1280 × 1024 / 60Hz, 1280 × 720 / 60Hz, 1024 × 768 / 60Hz
VGA output resolution
1920 × 1080p / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz,1024 × 768 / 60Hz
Audio output
1-ch, RCA (Linear, 1 KΩ)
Decoding
Decoding format
H.265 / H.265+ / H.264 / H.264+ / MPEG4
Live view / Playback resolution
12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Synchronous playback
16-ch
Capability
2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)
Network management
Network protocols
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA
4 SATA interfaces for 4HDDs
Capacity
Up to 6TB capacity for each HDD
External interface
Network interface
2 RJ-45 10 / 100 / 1000 Mbps self-adaptive Ethernet interfaces
Serial interface
1 RS-485 (half-duplex), 1 RS-232
USB interface
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm in / out
16 / 4
General
Power supply
100 to 240 VAC
Power
≤80 W
Consumption (without hard disk)
≤20 W
Working temperature
-10 to +55º C (+14 to +131º F)
Working humidity
10 to 90 %
Chassis
19-inch rack-mounted 1.5U chassis
Dimensions (W × D × H)
445 × 400 ×71 mm ( 17.5″× 15.7″ × 2.8″)
Weight (without hard disk)
≤ 5 kg (11 lb)
